Essential Oil Bottling Machine KI-SLF

Description
Specification

General Information:

We offer motorized operated a semi-automatic volumetric liquid filling machine. We have two head as well as four head models where only one operator will be occupied for two head model and two operators will be occupied for four head model. In the Semi-automatic machine, the filling process is operated continuously and automatically while the operator needs to place the empty bottles and remove the filled bottles manually after filling is done. These machines are provided with thunder pipes and in special case silicon pipes (for a hot product) to sustain longer life.

We can offer any customization in the machine as per the requirement of the customers. Machines are provided with non-return valves which give accurate and continuous filling output of all type of free flowing liquid in any shape of the container.

Machine Features

Volumetric Based Filling
Fill Accuracy ± 1 %
Well-designed Drip proof Nozzles.
Machine Body Painted covered with SS 304 sheet.
Easy change over parts
Teflon seals to avoid leakage
Adjustable Bottle guides
SS Tray for resting of bottles while filling
ON/OFF switch to start and stop the machine
Tightening/Loosening of Teflon piston in syringe to avoid leakage/variation
All Contact parts can be dissembled for cleaning purpose.

Optional Features

Full SS Construction
Dive-In Nozzles for Foamy liquids and also for small mouth diameter of the bottle.
Position Indicators for Volume Adjustment position indication.
Lockable wheels.
Siemens/ ABB/ Schneider/ Delta Make Variable Speed Drive for varying the speed of the motor to control filling speed.
Spring Nozzles to avoid dripping for thin products
Foot Switch based Operation to control the speed of filling
TC fittings for easy removal/change of parts for cleaning
Tank for storage of material to connect pipe from tank to filling machine

Filling Range

2 ml to 5000 ml with the help of change parts of syringes.
Filling range of 2-10 ml, 10-30ml, 30-100 ml, 50-250 ml, 100-500 ml, 250-1000 ml, 500 – 2500 ml, 1000 ml - 5000 ml are standards we define.

Product Range

PHARMACEUTICAL	Syrups, Suspensions, Linctus
COSMETIC	Nail Polish, Nail Polish Remover, Rose Water, Glycerine, Shampoo, Hair Oil, Hand Sanitizer,
FOOD & BEVERAGES	Alcoholic Drinks, Vitamin Drinks, Fruit Juices, Iced Tea, Edible Oil, Honey, Ghee, Flavoured Milk, Vinegar, Soya Sauce, Liquid Concentrate, Flavoured Syrups, Water,
OTHERS	Floor Cleaner, Paints, Chemicals, Lubricating Oils, Liquid Detergent, Essential Oil, Dishwashing Liquid, Toilet Cleaner.

Output

Up to 35 Bottles/Minute depending upon the number of heads, product viscosity, and density and also on the experience of the operator.

Electrical Specifications

Power Input	415 V ± 5 V AC Three Phase ( 220 V ± 5 V Single Phase on request)
Motor Capacity	0.5 HP to 2 HP varies as per filling size.

Material Construction

Available with SS 304 / SS 316 / SS 316 L contact parts as per the requirement. Complete machine construction in Stainless Steel can be provided.

Weight

Varies 50 – 100 kg approx as per the model.
